time-warp-test.c: check TSC synchronity on x86 CPUs
time-warp-test.c: check TSC synchronity on x86 CPUs. Also detects gettimeofday()-level time warps.
/*
* Copyright (C) 2005, Ingo Molnar
*
* time-warp-test.c: check TSC synchronity on x86 CPUs. Also detects
* gettimeofday()-level time warps.
*
* Compile with: gcc -Wall -O2 -o time-warp-test time-warp-test.c -lrt
*/
#include <stdio.h>
#include <stdarg.h>
#include <stdlib.h>
#include <signal.h>
#include <sys/wait.h>
#include <linux/unistd.h>
#include <unistd.h>
#include <string.h>
#include <pwd.h>
#include <grp.h>
#include <sys/stat.h>
#include <sys/types.h>
#include <sys/stat.h>
#include <sys/time.h>
#include <regex.h>
#include <fcntl.h>
#include <time.h>
#include <sys/mman.h>
#include <dlfcn.h>
//#include <popt.h>
#include <sys/socket.h>
#include <ctype.h>
#include <assert.h>
#include <sched.h>
#include <time.h>
#define TEST_TSC 1
#define TEST_TOD 1
#define TEST_CLOCK 1
#if !TEST_TSC && !TEST_TOD && !TEST_CLOCK
# error this setting makes no sense ...
#endif
#if DEBUG
# define Printf(x...) printf(x)
#else
# define Printf(x...) do { } while (0)
#endif
/*
* Shared locks and variables between the test tasks:
*/
enum {
SHARED_LOCK = 0,
SHARED_TSC = 2,
SHARED_TOD = 4,
SHARED_CLOCK = 6,
SHARED_WORST_TSC = 8,
SHARED_WORST_TOD = 10,
SHARED_WORST_CLOCK = 12,
SHARED_NR_TSC_LOOPS = 14,
SHARED_NR_TSC_WARPS = 16,
SHARED_NR_TOD_LOOPS = 18,
SHARED_NR_TOD_WARPS = 20,
SHARED_NR_CLOCK_LOOPS = 22,
SHARED_NR_CLOCK_WARPS = 24,
SHARED_END = 26,
};
#define SHARED(x) (*(shared + SHARED_##x))
#define SHARED_LL(x) (*(long long *)(shared + SHARED_##x))
#define BUG_ON(c) assert(!(c))
typedef unsigned long long cycles_t;
typedef unsigned long long usecs_t;
typedef unsigned long long u64;
#ifdef __x86_64__
#define DECLARE_ARGS(val, low, high) unsigned low, high
#define EAX_EDX_VAL(val, low, high) ((low) | ((u64)(high) << 32))
#define EAX_EDX_ARGS(val, low, high) "a" (low), "d" (high)
#define EAX_EDX_RET(val, low, high) "=a" (low), "=d" (high)
#else
#define DECLARE_ARGS(val, low, high) unsigned long long val
#define EAX_EDX_VAL(val, low, high) (val)
#define EAX_EDX_ARGS(val, low, high) "A" (val)
#define EAX_EDX_RET(val, low, high) "=A" (val)
#endif
static inline unsigned long long __rdtscll(void)
{
DECLARE_ARGS(val, low, high);
asm volatile("cpuid; rdtsc" : EAX_EDX_RET(val, low, high));
return EAX_EDX_VAL(val, low, high);
}
#define rdtscll(val) do { (val) = __rdtscll(); } while (0)
#define rdtod(val) \
do { \
struct timeval tv; \
\
gettimeofday(&tv, NULL); \
(val) = tv.tv_sec * 1000000ULL + tv.tv_usec; \
} while (0)
#define rdclock(val) \
do { \
struct timespec ts; \
\
clock_gettime(CLOCK_MONOTONIC, &ts); \
(val) = ts.tv_sec * 1000000000ULL + ts.tv_nsec; \
} while (0)
static unsigned long *setup_shared_var(void)
{
char zerobuff [4096] = { 0, };
int ret, fd;
unsigned long *buf;
fd = creat(".tmp_mmap", 0700);
BUG_ON(fd == -1);
close(fd);
fd = open(".tmp_mmap", O_RDWR|O_CREAT|O_TRUNC);
BUG_ON(fd == -1);
ret = write(fd, zerobuff, 4096);
BUG_ON(ret != 4096);
buf = (void *)mmap(0, 4096, PROT_READ|PROT_WRITE, MAP_SHARED, fd, 0);
BUG_ON(buf == (void *)-1);
close(fd);
unlink(".tmp_mmap");
return buf;
}
static inline void lock(unsigned long *flag)
{
#if 0
__asm__ __volatile__(
"1: lock; btsl $0,%0\n"
"jc 1b\n"
: "=g"(*flag) : : "memory");
#else
__asm__ __volatile__(
"1: lock; btsl $0,%0\n\t"
"jnc 3f\n"
"2: testl $1,%0\n\t"
"je 1b\n\t"
"rep ; nop\n\t"
"jmp 2b\n"
"3:"
: "+m"(*flag) : : "memory");
#endif
}
static inline void unlock(unsigned long *flag)
{
#if 0
__asm__ __volatile__(
"lock; btrl $0,%0\n"
: "=g"(*flag) :: "memory");
__asm__ __volatile__("rep; nop");
#else
__asm__ __volatile__("mov $0,%0; rep; nop" : "=g"(*flag) :: "memory");
#endif
}
static void print_status(unsigned long *shared)
{
const char progress[] = "\\|/-";
static unsigned long long sum_tsc_loops, sum_tod_loops, sum_clock_loops,
sum_tod;
static unsigned int count1, count2;
static usecs_t prev_tod;
usecs_t tod;
if (!prev_tod)
rdtod(prev_tod);
count1++;
if (count1 < 1000)
return;
count1 = 0;
rdtod(tod);
if (abs(tod - prev_tod) < 100000ULL)
return;
sum_tod += tod - prev_tod;
sum_tsc_loops += SHARED_LL(NR_TSC_LOOPS);
sum_tod_loops += SHARED_LL(NR_TOD_LOOPS);
sum_clock_loops += SHARED_LL(NR_CLOCK_LOOPS);
SHARED_LL(NR_TSC_LOOPS) = 0;
SHARED_LL(NR_TOD_LOOPS) = 0;
SHARED_LL(NR_CLOCK_LOOPS) = 0;
if (TEST_TSC)
printf(" | TSC: %.2fus, fail:%ld",
(double)sum_tod/(double)sum_tsc_loops,
SHARED(NR_TSC_WARPS));
if (TEST_TOD)
printf(" | TOD: %.2fus, fail:%ld",
(double)sum_tod/(double)sum_tod_loops,
SHARED(NR_TOD_WARPS));
if (TEST_CLOCK)
printf(" | CLK: %.2fus, fail:%ld",
(double)sum_tod/(double)sum_clock_loops,
SHARED(NR_CLOCK_WARPS));
prev_tod = tod;
count2++;
printf(" %c\r", progress[count2 & 3]);
fflush(stdout);
}
static inline void test_TSC(unsigned long *shared)
{
#if TEST_TSC
cycles_t t0, t1;
long long delta;
lock(&SHARED(LOCK));
rdtscll(t1);
t0 = SHARED_LL(TSC);
SHARED_LL(TSC) = t1;
SHARED_LL(NR_TSC_LOOPS)++;
unlock(&SHARED(LOCK));
delta = t1-t0;
if (delta < 0) {
lock(&SHARED(LOCK));
SHARED(NR_TSC_WARPS)++;
if (delta < SHARED_LL(WORST_TSC)) {
SHARED_LL(WORST_TSC) = delta;
fprintf(stderr, "\rnew TSC-warp maximum: %9Ld cycles, %016Lx -> %016Lx\n",
delta, t0, t1);
}
unlock(&SHARED(LOCK));
}
if (!((unsigned long)t0 & 31))
asm volatile ("rep; nop");
#endif
}
static inline void test_TOD(unsigned long *shared)
{
#if TEST_TOD
usecs_t T0, T1;
long long delta;
lock(&SHARED(LOCK));
rdtod(T1);
T0 = SHARED_LL(TOD);
SHARED_LL(TOD) = T1;
SHARED_LL(NR_TOD_LOOPS)++;
unlock(&SHARED(LOCK));
delta = T1-T0;
if (delta < 0) {
lock(&SHARED(LOCK));
SHARED(NR_TOD_WARPS)++;
if (delta < SHARED_LL(WORST_TOD)) {
SHARED_LL(WORST_TOD) = delta;
fprintf(stderr, "\rnew TOD-warp maximum: %9Ld usecs, %016Lx -> %016Lx\n",
delta, T0, T1);
}
unlock(&SHARED(LOCK));
}
#endif
}
static inline void test_CLOCK(unsigned long *shared)
{
#if TEST_CLOCK
usecs_t T0, T1;
long long delta;
lock(&SHARED(LOCK));
rdclock(T1);
T0 = SHARED_LL(CLOCK);
SHARED_LL(CLOCK) = T1;
SHARED_LL(NR_CLOCK_LOOPS)++;
unlock(&SHARED(LOCK));
delta = T1-T0;
if (delta < 0) {
lock(&SHARED(LOCK));
SHARED(NR_CLOCK_WARPS)++;
if (delta < SHARED_LL(WORST_CLOCK)) {
SHARED_LL(WORST_CLOCK) = delta;
fprintf(stderr, "\rnew CLOCK-warp maximum: %9Ld nsecs, %016Lx -> %016Lx\n",
delta, T0, T1);
}
unlock(&SHARED(LOCK));
}
#endif
}
int main(int argc, char **argv)
{
int i, parent, me;
unsigned long *shared;
unsigned long cpus, tasks;
cpus = system("exit `grep ^processor /proc/cpuinfo | wc -l`");
cpus = WEXITSTATUS(cpus);
if (argc > 2) {
usage:
fprintf(stderr,
"usage: tsc-sync-test <threads>\n");
exit(-1);
}
if (argc == 2) {
tasks = atol(argv[1]);
if (!tasks)
goto usage;
} else
tasks = cpus;
printf("%ld CPUs, running %ld parallel test-tasks.\n", cpus, tasks);
printf("checking for time-warps via:\n"
#if TEST_TSC
"- read time stamp counter (RDTSC) instruction (cycle resolution)\n"
#endif
#if TEST_TOD
"- gettimeofday (TOD) syscall (usec resolution)\n"
#endif
#if TEST_CLOCK
"- clock_gettime(CLOCK_MONOTONIC) syscall (nsec resolution)\n"
#endif
"\n"
);
shared = setup_shared_var();
parent = getpid();
for (i = 1; i < tasks; i++) {
if (!fork())
break;
}
me = getpid();
while (1) {
int i;
for (i = 0; i < 10; i++)
test_TSC(shared);
for (i = 0; i < 10; i++)
test_TOD(shared);
for (i = 0; i < 10; i++)
test_CLOCK(shared);
if (me == parent)
print_status(shared);
}
return 0;
}
